Large Scale Structures

Large Scale Structures

The nearly 10,000 galaxies captured in the Hubble Ultra Deep Field may look like they’re randomly scattered across the sky. But galaxies, including the Milky Way, are often part of larger structures and superstructures in space. Galaxy groups and clusters are collections of galaxies bound together by gravity. They are building blocks for the larger-scale structures of the universe.

The Hubble Deep Field
The Hubble Space Telescope captured this image, called the Hubble Ultra Deep Field, in 2004 by combining 800 images with a cumulative exposure of 11.3 days. It contains around 10,000 galaxies.
NASA

Galaxy Groups

Galaxy groups generally hold 100 or fewer galaxies. The Milky Way and its closest neighbors, including the Andromeda galaxy, live alongside over 50 other galaxies within the Local Group.

Galaxy Clusters

composite image of the Perseus Cluster
NASA’s Chandra X-ray Observatory captured this view of the massive Perseus cluster, one of the largest-known galaxy clusters. This structure contains thousands of galaxies immersed in an enormous cloud of superheated gas.
NASA/CXC/SAO/E. Bulbul, et al.

Galaxy clusters contain many more galaxies, from hundreds to thousands. The Coma cluster, for example, houses over 1,000 individual galaxies and stretches over 20 million light-years across.

In addition to their galaxies, these clusters also contain a lot of hot gas – tens of millions of degrees – and abundant amounts of dark matter, an invisible substance that scientists know must exist but have yet to identify.

Superclusters

Superclusters are large collections of galaxy clusters, groups, and individual galaxies that are typically not gravitationally bound to each other. The Local Group, containing the Milky Way, is located on the outer edges of the Laniakea supercluster.

The Intergalactic Medium

The Intergalactic Medium
Caltech’s Cosmic Web Imager captured this image of quasar 1549+19 surrounded by hydrogen (blue) and a filament of gas flowing inward from bottom left.
Christopher Martin (Caltech), Robert Hurt (Caltech)

The intergalactic medium is the gas and plasma – a mixture of electrons and atoms with an electric charge – found in the space between galaxies. It’s extremely hot, reaching millions of degrees, but it’s also very thin, only about one atom per cubic foot. For comparison, the “empty” space between stars may have 1,000 atoms per cubic foot. So, while the medium is hot, it’s so spread out that it’s dimmer than stars and other light-emitting matter within galaxies. This makes it difficult to detect.

Much of the intergalactic medium is made up of hydrogen and helium, the pristine gas left over from the big bang. But over cosmic history, the amount of heavier elements in the medium has increased. These elements include oxygen, neon, magnesium, silicon, and sulfur, and they are produced in stars as they burn and evolve. Supernovae, the explosions that mark the end of some stars’ lives, eject these elements into the medium.

Galactic Walls

Groupings of superclusters can form walls or sheets of galaxies. These walls are likely the largest-known superstructures within the observable universe. They can stretch hundreds of millions of light-years across but are relatively thin – only about 20 million light-years deep.

The first galactic wall astronomers discovered, called the Coma Wall, is about 500 million light-years long, 16 million light-years deep, and 300 million light-years away. Scientists have since identified additional walls, most notably the Sloan Great Wall, which spans about 1.4 billion light-years.

The Cosmic Web

Fly through the cosmic web, the large-scale structure of the universe, through this visualization. Each bright knot is an entire galaxy, while the purple filaments show material between them. To the human eye, only the galaxies would be visible. This visualization allows us to see the strands connecting galaxies and forming the cosmic web. Credit: NASA/NCSA University of Illinois Visualization by Frank Summers, Space Telescope Science Institute, Simulation by Martin White and Lars Hernquist, Harvard University

Galaxies, galaxy groups and clusters, superclusters, and galactic walls are arranged in twisting, threadlike structures called the cosmic web. The web forms as the gravitational attraction of the universe’s matter draws larger and larger objects together. This leads to concentrations of galaxies with voids of space in between, as if the galaxies were resting on empty bubbles. Where those concentrations intersect, they form larger structures like clusters and walls. The cosmic web forms a sort of scaffolding that cradles everything that exists within the universe.
